Collection: 4Low Concepts Air Ride Kit

Product Description

2. This air strut pack includes:

 4 * 4LOW CONCEPTS AIRRIDE Coilover shock absorber (2 for front and 2 for rear)

 4 * 4LOW CONCEPTS AIRRIDE Rubber air spring (2 for front and 2 for rear)

 2 * spacers + bolts

 4 * 1/8NPT air fittings

 4 * dampers

 2 * spanners (wrenches)

 2 * sway bar (optional if needed)

 2 * Pillow ball camber plate (optional and extra charge, please contact online service)

3. Features:

 32-level adjustable Damping

Allows you the ability to dial in your air suspension even further. Set damping softer (counterclockwise) or stiffer (clockwise) by simply inserting the included damping knob and turning it either way.

 Threaded & adjustable shock mounts

Adding further tuning of your ride height at any PSI setting you choose is the ability to have an adjustable mount just like coilover kits. The benefit to this is being able to get the perfect ride height at basically any PSI you are comfortable driving at.

 125mm drop (front & rear)

Front and rear air strut with 125mm drop (stroke) that lift & lower your car body at random. Works with 4LOW CONCEPTS AIRRIDE G5 air management for 3-level memorized height adjustment.

 High Pressure Double Bellows Progressive Rate Spring

Engineered and designed to match your vehicle, slim double bellow type bags are available depending on what type of OEM suspension your vehicle has. Air pressure directly corresponds with how stiff or soft your car rides. Higher PSI = stiffer ride. Lower PSI = softer ride. Each car is different and it may take some time to dial in your preferred settings.

 High Performance 4LOW CONCEPTS AIRRIDE Shock Absorbers

Every air strut kit comes with the same quality shocks that are standard in our coilover systems. Air strut shocks have a different internal valving setting to accommodate changes in PSI.

 12 Month Limited Warranty

Our warranty is 12 months from the original date of purchase which covers manufacturer defects.



Management System & Control Features

 Backlight Adjustable Manifold Valve: Choose between RED, GREEN, BLUE, and PURPLE backlighting.

 Wired Controller with Changeable Backlight: Select from RED, GREEN, or BLUE.

 V3 APP Interface: Switch between 3 unique background skins to match your style.

 Plug-and-Play Design: Extremely easy to connect and get up and running.

 Built-In Pressure Switch: Integrated directly inside the manifold solenoid valve for a cleaner setup.

 Maximum Stability: Features fully updated software with all bugs resolved for super stable performance.

 Premium Material Quality: Built with upgraded silicon chips and heavy-duty valves.

 Pre-Set Air Tank Pressure: Highly customizable compressor logic. When the air tank drops below your minimum set value, the air pump kicks on; once it hits your maximum set value, the pump automatically shuts off.

 Upgraded Faceplate: High-finish acrylic panel offers a cleaner look than standard alloy aluminum covers, allowing for much better wireless signal reception capability.

 Precision Control: 5-level preset memory with more accurate memory values and precise micro-adjustments.

 Extreme Working Temperature Range: Built to perform from -40^\circ\text{C} to 125^\circ\text{C} (-40^\circ\text{F} to 257^\circ\text{F}).

Air Management & Movement Logic

 Independent 4-Corner Control: Full independent rise and drop control for each wheel.

 Simultaneous Axle Control:

 Front 2 wheels rise/drop together.

 Rear 2 wheels rise/drop together.

 All 4 wheels rise/drop simultaneously.

 Micro-Adjustments: Four-wheel slight adjustment tuning for the perfect stance.

 Multiple Controller Options: Includes a sleek wired controller; wireless controller options are available.

 Smartphone Integration: Dedicated mobile app control available for both iOS and Android.

 Multi-Language Interface: 12 languages supported (English, Spanish, Japanese, French, Thai, Korean, Russian, Dutch, Arabic, German, Chinese, Traditional Chinese).

 Security Features: Custom changeable password protection and automatic security checking/adjusting.

 One-Touch Function: Long press the up/down button to ride all the way to the top or bottom of the stroke.

 Digital LED Pressure Display (PSI):

 Display precision: Up to 1 PSI

 Memory accuracy: Up to 3 PSI

 Maximum Lift/Drop: Accommodates a massive total car body stroke of 5.9 inches.

CONFIGURATION LIST:

1. 4LOW CONCEPTS AIRRIDE Wired Controller * (1 piece)

2. Manifold Solenoid Valve * (1 piece)

3. Premium Wiring Harness + Air Fittings & Connectors * (1 set)

4. Instruction Manual * (1 piece)
